Intelligent heating systems reduce energy consumption in buildings by up to 15 per cent
Data-driven heating reduces energy consumption in buildings.
As prices shoot through the roof, business property managers are having to get smarter at controlling energy consumption – and heating offers a lot of potential savings.
Only heat buildings by as much as they need
The Norwegian research institute SINTEF is currently working with software developers Kiona and property managers DNB Næringseiendom to find out how we can heat our buildings more intelligently.
As part of a project called Databygg, algorithms are being developed that can regulate the temperature in the heat distribution system of a building based on its heating needs.
Traditionally, the temperature of the water that is fed into heating radiators (the so-called flow temperature) is dependent on the outdoor temperature. The colder it is outside, the higher the flow temperature.
Such systems are designed to boost energy efficiency, but nevertheless fail to take the actual heating needs of buildings adequately into account.
“The control algorithm that we are developing in this project takes account not only of the outdoor temperature, but also of weather forecasts and the planned utilisation of the buildings,” Åsmund Svinndal says.
He is the chief business development officer who is responsible for research and development at Kiona.
“Our aim is to supply exactly as much energy as is needed to maintain the desired room temperature,” he says.
Saving energy from the first day
Based on detailed measurements taken over a period of two years, a data-driven model has been developed for the predictive control of the heating system. The model is able to predict the room temperature that will be achieved for a given radiator flow temperature.
“However, it emerged that the variation in the data was too limited to be able to train the model to function as intended,” John Clauss says.
He is a research scientist at SINTEF and is the Databygg project manager.
For this reason, algorithms were developed that automatically and continuously adjust the radiator temperature in response to the measured room temperature.
The algorithms record the room temperature once every 30 minutes as a basis for determining if there is a need to provide heating. If heating is not required, the temperature in the radiator circuit is reduced. If the room temperature falls and the rooms become too cold, the flow temperature is increased again.
The likelihood of poorer thermal comfort developing is low if the temperature is checked at 30-minute intervals.
Energy consumption reduced by 10 - 15 per cent
The system was tested in an office building in the centre of Trondheim in central Norway last autumn.
Energy used for heating was reduced by between 10 and 15 per cent while maintaining desired room temperatures. Moreover, the temperature in the radiators was increased gradually in order to avoid energy peaks occurring when the flow temperature was increased.
“The algorithms have helped the system to save energy from day one,” Erlend Kaland Simonsen says.
He is director of Development and Digitalisation at DNB Næringseiendom.
Enhanced model will save even more energy
As well as saving energy, the implemented algorithms generate more data that in turn can be used to train models with the aim of predicting future room temperatures more accurately. These models will be applied in the future as part of a predictive control algorithm that can anticipate heating needs.
This algorithm uses new data to solve an optimisation problem generated once every hour. Based on data generated by measurements taken in the building, the algorithm suggests a flow temperature that will ensure the desired room temperature for the following 12 hours. This will contribute to further energy savings.
“Our intention is to utilise predictive algorithms in several of our buildings,” Simonsen says. “Before summer this year, we will also be looking into how we can reduce energy consumption in our cooling system."
About the Databygg project
The Databygg project is an IPN (Innovation for Business) project funded by the Research Council of Norway, with a total budget of 2.5 million USD. Kiona is acting as Project Manager, while DNB Næringseiendom and SINTEF are assigned the roles of project partner and R&D partner, respectively. The project will run until the end of 2023.
