This article was produced and financed by Nofima The Norwegian Institute of Food, Fisheries and Aquaculture Research

The SmartSensor project is a three-year project that began in 2016. They're developing a new sensor to make sure that sausages are cooked at just the right temperature. (Photo: Shutterstock)

Smart sensor technology could mean better sausage and chips

Full temperature control leads to better sausages, and control of water content means better chips: new study.

Nofima The Norwegian Institute of Food, Fisheries and Aquaculture Research

Nofima is a business oriented research institute working in research and development for the aquaculture, fisheries and food industry in Norway.

Researchers from Nofima and Sintef Digital in Norway are developing an instrument that can rapidly take key measurements of food in the production line.

It is called the SmartSensor project.

"This type of instrument will be of great value to food manufacturers because better control will make it easier to handle variable quality of raw materials, which will reduce waste.  We have now completed the development of Prototype version 2, which is currently being tested in companies,” says Jens Petter Wold, senior researcher at Nofima and project manager.

Better control = boost to profitability

For Nortura, the main point is better control of the core temperature in hot dog sausages.

Sausages that are safe to eat must have a core temperature above 72°C, but if the temperature exceeds 78°C, they lose more water than necessary, become less juicy, and profitability decreases.

Today, core temperatures are measured by sampling when necessary. But the new prototype continuously measures and adjusts the temperature if it is not on target.

"Measuring the core temperature of each sausage as they pass through the oven has been both challenging and enjoyable.  Water vapour, humidity, little space, and the fact that we couldn’t see the sausages we were measuring, made this quite a job.  But we solved many of the problems through close cooperation between Nortura, Nofima, and Sintef,” says Sintef researcher Marion O'Farrell.

The tech can also be used to bake the perfect chip. The amounts of dry matter and water varies enourmously among potatoes. Findus wanted to be able to measure the water content of potatoes and potato strips during the production process. Potatoes with too little dry matter can be removed and used for other products, and the frying process can be adjusted optimally in terms of the water content of the potato strips, resulting in deliciously crisp chips and French fries. The scienitsts have been able to accurately measure the dry matter in each potato in the lab, and have now obtained very promising results from process measurements as well.

In addition, the salmon producer Cermaq wanted to find out whether the technology can be used to measure the quality of whole salmon. This will enable better production management at the individual level and make production more customer-friendly.

Further advances

The technology in the prototype is based on the use of near-infrared spectroscopy (NIR). The prototype is unique in its capability to measure extremely quickly, and at the same time to take measurements from deep inside the food item. For example, it can measure beneath salmon skin, without contact with the food.

"We have previously developed rapid measuring instruments for use on production lines, but these were unable to penetrate deep enough into products with dark surfaces like salmon and potato skin.  We have developed instruments that can penetrate dark surfaces, but these needed to have contact with the food, and were therefore unsuitable for measurements in the production line. In this project, we are working towards combining both of these desirable effects, and this will save food manufacturers a lot of money,” says Jens Petter Wold.

The three companies involved in the project have calculated that the use of an effective instrument can lead to considerable annual savings, based on better yields, consistent product quality,less waste and added value in the market.

”Today we have a promising prototype, and we believe and hope that this will eventually become a commercial product. TOMRA is the technology supplier and the instrument is based on some of their technology.  We hope the results will be so good that TOMRA will commercialise it to the benefit of the food industry,” concludes Jens Petter Wold.
